Technical Specifications
Audio
Frequency Response: 100 Hz-15 kHz, +0/-3 dB
Impedance: >10K Ohms (bridging)
Clear-Com or compatible: -15 dBv nominal
Other: -10 dBv nominal
Call Signal
Clear-Com or compatible only: 4 -11 VDC
Nulling Capability
Line Length: 0 – 4,000 feet
Line Impedance: 120 – 350 Ohms
Depth of Null: >30 dB, 200 Hz – 8 kHz
Nulling Tone: Via 1/8″ phone jack
Power
Power is supplied by external partyline
Consumption (maximum each channel): 40 mA @ 20 – 30 VDC
Power Requirements: 0 mA from PSU-101 power supply
Environmental
Operating Temperature: 32°F – 104°F (0°C – 40°C)
Storage Temperature: -67°F – 158°F (-55°C – 70°C)
Humidity: 90% non-condensing
Dimensions
5.06 x 1.38 x 9.16 in (HxWxD)
129 x 35 x 233 mm)
Weight
12.5 oz (0.32 kg)
Features and/or Benefits
Provides Partyline Ring Connectivity
Connect 2-wire partyline circuits to Eclipse HX matrices, providing a partyline ring between systems.
