Technical Specifications
Maximum cards per frame: 7
Ports per card: 64
Audio
Channel Settings: 16, 32 and 64
Sample Rates: 44.1, 48 and 96kHz
Bit Depth: 24 bits
Master Clock: Configurable; generate or receive
Input Level Control Range: For each channel, the gain is configurable between 0dB and -45dB
Output Level Control Range: For each channel, the gain is configurable between 0dB and -45dB
VOX Setting Range: Between 0dBFS and -45dBFS, in 1dB increments
Connectors
RJ-45 (x2): 100 Mbps/1 Gbs; auto-sensing ethernet, primary and secondary network interfaces
SFP Cage (x2): SFP transceivers, primary and secondary network interfaces
Environmental
Operating Temperature: +32° F to +113° F (0° C to +45° C)
Storage Temperature: -22° F to +158° F (-30° C to +70° C)
Humidity: 90%, non-condensing
Dimensions
Height:
6RU (vertically in Eclipse HX-Median and Omega frames, or horizontally in Eclipse HX-Delta frames)
Depth:
Front Panel: 11.8in (300mm)
Rear Panel: 2.28 (58mm)
Weight
Front Card: 1.64lbs (0.75kg)
Rear Card: 9.2oz (0.26kg)
Features and/or Benefits
Seamless Connectivity
Interface cards enable the matrix system to become the ultimate central hub for linking audio channels with a variety of connectivity options – such as IP, Dante, wireless, MADI, analog, and fiber.
